Base Engine Warranty | Duration Whichever Occurs First | |
Month | Hours | |
Standby Power Rating | 24 | 400 |
Unlimited Time Running Prime Power Rating | 12 | Unlimited |
Limited Time Running Prime Power Rating | 12 | 750 |
Continuous/Base Power Rating | 12 | Unlimited |
Reference Standards of power ( BS-5514 and DIN-6271 standards are based on ISO-3046).
Base Engine Warranty | |
Duration Whichever Occurs First Hours | |
Month | Hours |
24 | 2000 |
Note: If the operating hours exceed the 2000-hour limit in the first year, the warranty shall remain valid until the end of the first year. | |
l Extended Warranty for Four Major Components (Engine Cylinder Block, Camshaft, Crankshaft, Connecting Rod): 3 years or 10,000 hours, whichever occurs first.
l Warranty for Belts and Hoses Provided by Chongqing Cummins(CCEC): 500 hours or 1 year, whichever occurs first.
Documents | Description |
Commission Document/Report, with ESN(Engine Serial Number) and Equipment No. | This document verifies that the engine has been installed and commissioned in accordance with Cummins specifications, and serves as the primary evidence to confirm the start date of the warranty period. |
Invoice/Agreement, with ESN and Equipment No. | This document confirms the legal purchase of the unit, establishing ownership and the date of sale for warranty validation. |
Clearance Document, with ESN and Equipment No. | This document verifies that the engine/equipment has been legally imported into the target market, completing all required customs formalities. |
Customs declaration/Waybill, with ESN and Equipment No. | This document confirms the legality of the export/transport process and provides traceability of the engine's shipment and delivery path. |
Equipment Info | Warranty Start Document | Remarks |
1. ESN 2. Model 3. OEM 4. Equipment No. 5. Location 6. Running Hour | 1. Commissioning Report 2. Purchase Invoice 3. Clearance Doc. 4. Shipping Doc. | Ø Warranty support document must be with ESN and Equip No. Ø If no document provided, we use built date +1 month as the last option. Ø If customer does not provide the customer information or warranty document to identify warranty start date, local Cummins service team may refuse the warranty work. |
1. Apply light lubricant or rust inhibitor to unpainted machined surfaces.
2. Apply light lubricant or rust inhibitor to any visible, unpainted internal cast surfaces (such as coolant inlet and outlet connections).
3. Seal all engine and component openings with clean protective caps, heavy paper and tape to prevent dirt and moisture from entering the engine.
4. Remove all external drive belts.
5. Install appropriate desiccants on the engine to absorb any moisture.
6. Cover the entire engine with a plastic sheet.
7. Move the engine or equipment to a suitable storage area.
(1) The storage area must be dry and have a uniform temperature. The recommended storage temperature is between -12°C (10°F) and 49°C (120°F), with a relative humidity below 60%.
1. Change the engine oil.
2. Replace the engine oil filter.
3. Verify that the cooling system is filled with fully formulated, approved coolant.
4. Use the Fleetguard® Coolant Test Kit CC2602 to measure the concentration of Supplemental Coolant Additive (SCA) and adjust as necessary.
5. Inspect the coolant quality annually during storage.
6. Replace the fuel filter.
7. Verify that the fuel supply line in the fuel tank contains only diesel fuel (0% biodiesel).
8. If any biodiesel is present in the fuel system, it will degrade during storage and damage the system.
9. Start the engine and operate it for 30 minutes until the coolant reaches normal operating temperature.
10. Shut down the engine.
1. Verify that the fuel supply in the fuel tank contains only pure diesel fuel (0% biodiesel content).
2. If any biodiesel is present in the fuel system, it will degrade and damage the system during storage.
3. Start the engine and run it for 30 minutes until the coolant reaches normal operating temperature.
1. Drain the engine oil.
2. Drain the coolant.
3. Apply light lubricant or rust inhibitor to all unpainted machined surfaces.
4. Apply light lubricant or rust inhibitor to any visible, unpainted internal cast surfaces (such as coolant inlet and outlet connections).
· Check operator logs
· Engine oil level
· Coolant level
· Engine air intake piping connections
· Air intake restriction indicator
· Leaks check (oil, coolant, air)
· Drive belts
· Fuel water separator
· Crankcase breather condition
· All items in Service Level A
· Replace
· Engine oil
· Oil filters (full-flow and bypass)
· Coolant filter (select appropriate filter based on DCA(Supplemental Coolant Additive) concentration)
· Fuel filter
· Inspect or clean
· Air filter and intake restriction
· Intake system and breather lines
· Check DCA concentration in the cooling system
· Check heat exchanger plugs (marine engines)
· All items from Service Level A and Service Level B
· Adjust valve clearance and injector stroke
· Clean crankcase breather screen
· Replace engine coolant
· Inspect:
§ Engine protection system
§ Turbocharger mounting bolts
§ Front and rear support mounting bolts
§ Crankshaft end play
· All items from Service Level A, B and C
· Calibrate
· Fuel injectors
· Fuel pump
· Clean the engine cooling system
· Inspect:
· Turbocharger axial and radial clearances
· Check if the viscous damper is functional
· Air compressor exhaust pipe carbon deposits and check unloader function
· Fan hub
· Belt tensioner bearing
· Belt tension condition
